Space Management Solutions – Page 2

Showing 13–24 of 27 results

Acoustic Operable Partition – Variflex Semi Automatic 88 – 58dB

The function oriented movable wall system for everyday use. Space can be partitioned in a wide range of configurations to suit any architectural design requirements. Unsurpassed flexibility, reliable sound insulation, ease of operation coupled with superior quality and aesthetics guarantees effective space management.

Element thickness: 88 mm Element width (min. / max.): 600 – 1200mm Clear height (min. / max.): 2000 – 4000mm Construction Type:Non deflecting steel tubes with aluminium profiles. Face Panel fixing:MDF panel hung on the hanging rods and allowed to freely oscillate. Element interconnection / design of the vertical profiles:Aluminium profile with integrated magnetic strip and sealing lip forming a contact pressure of 40 N/m . Cover Panel design with K-type edge:With visible surface edge.

Standards: Sound attenuation defined to EN 10140, in Rw:58dB

View Product
Acoustic Operable Partition – Variflex Semi Automatic ML88 – 53dB

The function oriented movable wall system for everyday use. Space can be partitioned in a wide range of configurations to suit any architectural design requirements. Unsurpassed flexibility, reliable sound insulation, ease of operation coupled with superior quality and aesthetics guarantees effective space management.

Element thickness: 88 mm Element width (min. / max.): 600 – 1200mm Clear height (min. / max.): 2000 – 4000mm Construction Type:Non deflecting steel tubes with aluminium profiles. Face Panel fixing:MDF panel hung on the hanging rods and allowed to freely oscillate. Element interconnection / design of the vertical profiles:Aluminium profile with integrated magnetic strip and sealing lip forming a contact pressure of 40 N/m . Cover Panel design with K-type edge:With visible surface edge.

Standards: Sound attenuation defined to EN 10 140, in Rw:53dB

View Product
Acoustic Operable Partition – Varitrans Comfort Drive

Fully Automatic Glass Partition with less weight. A Partition that helps to divides the room automatically without human interference.

Element thickness: 30 mm Element width (min. / max.): 600 – 1200mm Clear height (min. / max.): 2000 – 4000mm 1. Single / double leaf door 2. Magic Glass (By Others)

View Product
Acoustic Operable Partition – Vartflex Manual 88 – 46dB

The function oriented movable wall system for everyday use. Space can be partitioned in a wide range of configurations to suit any architectural design requirements. Unsurpassed flexibility, reliable sound insulation, ease of operation coupled with superior quality and aesthetics guarantees effective space management.
Sound attenuation defined to EN 10 140, in Rw:46dB

Element thickness: 88 mm Element width (min. / max.): 600 – 1200mm Clear height (min. / max.): 2000 – 4000mm Construction Type:Non deflecting steel tubes with aluminium profiles. Face Panel fixing:MDF panel hung on the hanging rods and allowed to freely oscillate. Element interconnection / design of the vertical profiles:Aluminium profile with integrated magnetic strip and sealing lip forming a contact pressure of 40 N/m . Cover Panel design with K-type edge:With visible surface edge.

Standards: Sound attenuation defined to EN 10 140, in Rw:46dB

View Product
ACOUSTIC OPERABLE PARTITION VARIFLEX SOLID 100 – SEMI AUTOMATIC

The operable acoustic partition system consists of 100mm thick, individually movable elements, suspended from a top track only. Each panel features top and bottom operable pressure seals activated automatically by a 24V DC motor, ensuring optimum contact pressure up to 800N. The elements are interconnected by a positive locking convex/concave aluminum profile, integrated with magnetic strips having a linear attraction of 40 N/m. Elements are constructed of a non-deflecting steel tube frame and aluminum profiles, bolted together. The frame is clad on either side with 16 mm MDF panels, hung in acoustic isolation from the frame and allowed to vibrate independently. The facia panels are easily removable. The panel interior is filled with high-density rock wool to meet specified sound insulation requirements. The telescopic element opens and closes 120 mm and is operated by a single mechanism for both the top and bottom seals.

Key Features and Specs:
Standards: Sound attenuation defined to EN 20 140, in Rw: 45dB / 50dB / 52dB / 53dB / 55dB
Area of Application: Training rooms, Classrooms & Boardrooms, Banquet halls, Convention Halls.
Advantages: Easy to operate the panel, Less human interference, Operational time is less.
Dimensions:
Element thickness: 100mm
Element width (min. / max.): 850 – 1200 mm
Clear height (min. / max.): 2000 – 12000mm
Contact pressure of horizontal sealing strips per element: 800 N
Track system: R type / smart track
Options:
Single / double leaf door, Vision panel, Angled Panel, Door with Vision Panel
Mode of Operation: Elements moved manually, supported by electronically controlled extension and retraction of the sealing strips and telescopic element.

View Product
ACOUSTIC OPERABLE PARTITION VARIFLEX STANDARD 85 – MANUAL

The operable wall system comprises individually movable panels, 85mm in thickness, suspended from a top track. Each panel features top and bottom operable pressure seals, activated by a crank handle, ensuring a contact pressure of 800N. The panels are interconnected via a positive locking concave/convex aluminum profile. Each panel incorporates a non-deflecting steel tube frame and aluminum profiles, bolted together. 16mm MDF panels are mounted on either side, acoustically isolated from the frame to allow for independent vibration. Facia panels are easily removable. The panel interior is filled with high-density rock wool to achieve the specified sound insulation. A telescopic element allows for 120mm of opening and closing, operated by a single mechanism for both top and bottom seals.

Key Features and Specs:
Options: Single leaf door
Dimensions:
Horizontal Sealing Strip Contact Pressure: 800 N per element
Clear Height: 2000 – 4100 mm
Element Width: 600 – 1200 mm
Element Thickness: 85mm
Standards: Sound attenuation defined to EN 20140, in Rw: 45dB, 50dB
Area of Application:
Conference & Meeting Rooms, Kitty Halls,Cafeterias, Restaurants, and other.
Advantages: Economical partition with minimum sound reduction requirement

View Product
ACOUSTIC OPERABLE PARTITION VARIFLEX STANDARD 85 – MANUAL

The operable wall system consists of individually movable elements, 100mm thick, suspended from a top track only. Each panel has top and bottom operable pressure seals, operated by a crank handle, to ensure optimum contact pressure up to 800N. The elements are interconnected by a positive locking concave/convex aluminum profile, integrated with a magnetic profile to ensure a contact pressure of 40N/m. Each element is suspended on multi-directional rollers. Elements are constructed of a non-deflecting steel tube frame and aluminum profiles, bolted together. The frame is clad on either side with 16mm MDF panels, hung in acoustic isolation from the frame and allowed to vibrate independently. Facia panels are easily removable. The panel interior is filled with high-density rock wool to meet specified sound insulation requirements. The telescopic element opens and closes 120mm and is operated by a single mechanism for both the top and bottom seals. The system includes an R-type/smart track, and offers optional single or double-leaf pass doors, angled panels, and doors with vision panels.

Key Features and Specs:
Standards: Sound attenuation defined to EN 20140, in Rw: 45dB / 50dB / 52dB / 53dB / 55dB.
Area of Application: Training rooms, Classrooms & Boardrooms, Convention centers, Banquet halls.
Advantages: Best suited for high sound reduction applications, Can be used up to 15m in partition height.
Dimensions:
Element thickness: 100 mm
Element width (min. / max.): 800 – 1200mm
Clear height (min. / max.): 2000 – 15000mm
Contact pressure of horizontal sealing strips per element: 800 N
Track system: R type / smart track
Options: Single / double leaf door, Vision panel, Angled Panel, Door with Vision Panel.
Mode of Operation: Manual operation of the elements and actuation of the sealing strips.

View Product
Acoustic Operable Partition Variflex Top 100 – Manual

The function oriented movable wall system for special need of high acoustic. Space can be partitioned in a wide range of configurations to suit any architectural design requirements. Unsurpassed flexibility, reliable sound insulation, ease of operation coupled with superior quality and aesthetics guarantees effective space management.

Element thickness: 100 mm Element width (min. / max.): 800 – 1200mm Clear height (min. / max.): 2000 – 9000mm Contact pressure of horizontal sealing strips per element: 800 N Track system: R type / smart track 1. Single / double leaf door Mode of Operation :Manual operation of the elements and actuation of the sealing strips.

Standards: Sound attenuation defined to EN 20 140, in Rw: 57dB

View Product
Acoustic Operable Partition Variflex Top 100 – Semi Automatic

The user-friendly partitioning solution combined with operating convenience, excellent cost efficiency and high acoustics properties makes Variflex Semi-Automatic to satisfy all requirements that arise in applications requiring flexible space division, sophisticated surface finish and acoustic efficiency. Electronic extension and retraction of sealing strips enables the user to save time, energy and cost while increasing the whole system efficiency.

Dimensions:
Element thickness: 100 mm Element width (min. / max.): 850 – 1200mm Clear height (min. / max.): 2000 – 9000mm Contact pressure of horizontal sealing strips per element: 800 N Track system: R type / smart track 1. Single / double leaf door Mode of Operation :Elements moved manually supported by electronically controlled extension and retraction of the sealing strips and telescopic element.
Standards: Sound attenuation defined to EN 20 140, in Rw:57dB

View Product
ACOUSTIC OPERABLE PARTITION VARIFLEX TOP 120 – MANUAL

The operable wall system consists of individually movable elements, 120mm thick, suspended from a top track only. Each panel has top and bottom operable pressure seals, operated by a crank handle, to ensure optimum contact pressure up to 800N. The elements are interconnected by a positive locking concave/convex aluminum profile, integrated with a magnetic profile to ensure a contact pressure of 40N/m. Each element is suspended on multi-directional rollers. Elements are constructed of a non-deflecting steel tube frame and aluminum profiles, bolted together. The frame is clad on either side with 16mm MDF and 10mm MDF panels, hung in acoustic isolation from the frame and allowed to vibrate independently. The facia panels are easily removable. The panel is filled with high-density rock wool to meet the specified sound insulation requirements. The telescopic element opens and closes 170mm and is operated by a single mechanism for both the top and bottom seals. The system includes an R-type/smart track and an optional single-leaf pass door.

Key Features and Specs:
Standards: Sound attenuation defined to EN 20 140, in Rw: 58dB, 60dB
Area of Application: Training rooms, Classrooms & Boardrooms,
Convention centers, Banquet halls.
Advantages: Best suited for high sound reduction application, Can be used up to 9m in partition height.
Dimensions:
Element thickness: 120 mm
Element width (min. / max.): 800 – 1200mm
Clear height (min. / max.): 2000 – 9000mm
Contact pressure of horizontal sealing strips per element: 800 N
Track system: R type / smart track
Options: Single leaf door.
Mode of Operation: Manual operation of the elements and actuation of the sealing strips.

View Product
ACOUSTIC OPERABLE PARTITION VARIFLEX TOP 120 – SEMI AUTOMATIC

The operable acoustic partition system consists of 120mm thick, individually movable elements, suspended from a top track only. Each panel features top and bottom operable pressure seals activated automatically by a 24V DC motor, ensuring optimum contact pressure up to 800N. The elements are interconnected by a positive locking convex/concave aluminum profile, integrated with magnetic strips having a linear attraction of 40 N/m. Elements are constructed of a non-deflecting steel tube frame and aluminum profiles, bolted together. The frame is clad on either side with 16 mm MDF panels and 10mm MDF, hung in acoustic isolation from the frame and allowed to vibrate independently. The facia panels are easily removable. The panel interior is filled with high-density rock wool to meet specified sound insulation requirements. The telescopic element opens and closes 120 mm and is operated by a single mechanism for both the top and bottom seals.

Key Features and Specs:
Standards: Sound attenuation defined to EN 20 140, in Rw: 58dB, 60dB
Area of Application: Training rooms, Classrooms & Boardrooms, Convention centers, Banquet halls
Advantages: Easy to operate the panel, Less human interference, Operational time is less
Dimensions:
Element thickness: 120 mm
Element width (min. / max.): 850 – 1200mm
Clear height (min. / max.): 2000 – 9000mm
Contact pressure of horizontal sealing strips per element: 800 N
Track system: R type / smart track
Options: Single /Double door
Mode of Operation: Elements moved manually, supported by electronically controlled extension and retraction of the sealing strips and telescopic element.

View Product
Argus Sensor Barrier

The Argus 80 is a visually appealing interlock system featuring an integrative aluminium profile design with a Full Cast Layer and wraparound covers, offering extensive colour customization options. 1 It incorporates vertically installed, design-oriented drive and locking components (75 mm diameter) on the guiding element, along with two transparent, impact-resistant plastic door leaves with an upper edge height of 990 mm. Its software ensures low energy movement compliant with DIN 18650 / EN 16005 by adapting speed to door mass, while the integrated control system operates on 100–240 VAC with low standby power consumption. The system provides motorized, electronically controlled movement in both entrance and exit directions upon release signals, with entry monitored by a vertical sensor and passage by a leg-area sensor strip, detecting unauthorized direction and triggering alarms. Advanced sensors include a sneak-by guard, minimizing false alarms and enabling trolley passage, and the door leaves can be locked in any position to prevent unauthorized use. The same sensors manage separation and monitor the swinging area, immediately stopping or decelerating movement if triggered to prevent injury. Certifications include emergency exit approval with optional components, EPD, CB Scheme, UL Certification and tested control unit for North America, and RoHS compliance. The system offers a passage width of 650 mm, a total width of 1060 mm, an interlock height of 995 mm, an interlock length of 1660 mm, and a guiding element width of 130 mm

Dimensions:
Passage width: 650 mm
Total width: 1060 mm
Interlock height: 995 mm
Interlock length: 1660 mm
Guiding element width: 130 mm
Wide range of colour combinations &, fit in with the respective architecture available

View Product
